PB90W

Features:

• Joins two 90 Series profiles (not included) at various angles up to 90 degrees.
• Shoulder screw and nylon washers allow for a smoother and easier adjustments. (optional)
• Handle provides a tension lock for adjustable maintained angle positions. (optional)
• Hardware is optional
• Recommended Hardware: M8 Lock Handle, M8 Shoulder Screw, and various M8 Washers, Button Heads and T-nuts to mount to your frame. (optional)

Machining Required:

• Drill M8 clearance hole 10mm from the top of the pivot point’s strut (shown vertical)

Technical Specifications:

• Material 6061 Aluminum
• Color Silver
